Banner USA Series Protective Mounting Stands - Manual (Page 2)

USA Series Protective Mounting Stands
2
Banner Engineering Corp. • Minneapolis, U.S.A.
Website: http://www.baneng.com • Tel: 612.544.3164
Figure 1. USA Series Protective Stand dimensions
1651 mm
(62.0")
1016 mm
(40.0")
25.4 mm
(1.00")
USA-PMS-40 USA-PMS-62
9.5 mm
(0.38")
25.4 mm
(1.00")
12.7 mm
(0.50")
63.5 mm
(2.50")
25.4 mm
(1.00")
50.8 mm
(2.00")
50.8 mm Typ.
(2.00")
25.4 mm Typ.
(1.00")
7.1 mm Wide Typ.
(0.28")
7.1 mm Wide Typ.
(0.28")
2x
174.2 mm
(6.86")
51 mm
(2.0")
89 mm
(3.5")
25.4 mm
(1.00")
9.5 mm
(0.38")
63.5 mm
(2.50")
25.4 mm Typ.
(1.00")
2x
174.2 mm
(6.86")
2x
203.2 mm
(8.00")
2x
330.2 mm
(13.00")
51 mm
(2.0")
89 mm
(3.5")
Note: Due to the variety of mounting situations, mounting hardware is not included with these stands.
