MSM Series Corner Mirrors
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp. will repair or
replace, free of charge, any product of its manufacture found to be defective at the time it is returned to the factory during the warranty
period. This warranty does not cover damage or liability for the improper application of Banner products. This warranty is in lieu of any
other warranty either expressed or implied.
Maximum
Excess
Gain
Required
Operating
Environment
1.5x
Clean air: no dirt buildup on
lenses or mirrors
5x
Slightly dirty: slight buildup
of dust, dirt, oil, moisture,
etc. on lenses or mirrors.
Lenses and mirrors cleaned
on a regular schedule.
10x
Moderately dirty: obvious
contamination on lenses or
mirrors (but not obscured).
Lenses and mirrors cleaned
occasionally or when
necessary.
50x
Very dirty: heavy
contamination on lenses and
mirrors. Heavy fog, mist,
dust, smoke, or oil film.
Minimal cleaning of lenses
and mirrors.
Guidelines for Excess Gain Values Excess Gain
Given the range from the above chart, excess gain can be calculated for any distance
by using the inverse square law. For example, the excess gain for a 30' range MINI-
SCREEN system at a 10' separation, using two corner mirrors, is calculated as
follows:
E.G. = (25.5') 2 = 6.5 E.G. = (1x) (6.5) = 6.5x
1x (10') 2
For the same situation at a 10' separation, using MACHINE-GUARD sensors:
E.G. = (38') 2 = 14.4 E.G. = (3x) (14.4) = 43x
3x* (10') 2
*Note: MACHINE-GUARD sensor range is the separation between emitter and receiver
where 3x excess gain remains.
