Installation
Banner MSA Series Protective Mounting Brackets may mount directly to a wall or
post, or to the machine frame. They may be used individually, or in pairs, to provide
maximum protection. When used in pairs, the two stands form a U-configuration,
with the sensor recessed well back from the front of the bracket’s outer edges.
Figure 2. One- or 2-bracket configurations
This surface
towards the
source of
material
or path of
object
Emitted Light
Path
Emitted Light
Path
Or mount two together
to form a U-channel
to protect all sides
One Protective Bracket
protects back and one
side of sensor
