System Description
Emitter/Receiver
Model
MAHE64A Emitter
MAHR64A Receiver
1626 mm (64.0")
MAHE6A Emitter
MAHR6A Receiver
MAHE77A Emitter
MAHR77A Receiver
1951 mm (76.8")
MAHE13A Emitter
MAHR13A Receiver
MAHE19A Emitter
MAHR19A Receiver
MAHE26A Emitter
MAHR26A Receiver
MAHE32A Emitter
MAHR32A Receiver
MAHE38A Emitter
MAHR38A Receiver
MAHE45A Emitter
MAHR45A Receiver
MAHE51A Emitter
MAHR51A Receiver
MAHE58A Emitter
MAHR58A Receiver
MAHE70A Emitter
MAHR70A Receiver
Array Length Y*
163 mm (6.4")
325 mm (12.8")
488 mm (19.2")
650 mm (25.6")
813 mm (32.0")
975 mm (38.4")
1138 mm (44.8")
1300 mm (51.2")
1463 mm (57.6")
1788 mm (70.4")
640
768
Total
Beams
64
128
192
256
320
384
448
512
576
704
Emitter and Receiver Models
Cables
Configure and monitor the
System with the supplied
software and any
PC-compatible computer
(running Windows® XP,
Vista, or 7), via an RS-232
cable.
High-Resolution
Receiver
High-Resolution Emitter
DIN-
Rail Mountable
Control Module
Figure 1-1. A-GAGE High-Resolution MINI-ARRAY System components
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Controller
Model
Solid-State
Discrete Outputs
Analog
Outputs
MAHCVP-1 2 PNP (2) 0-10V Sourcing
MAHCVN-1 2 NPN (2) 0-10V Sourcing
MAHCIP-1 2 PNP (2) 4-20 mA Sinking
MAHCIN-1 2 NPN (2) 4-20 mA Sinking
Quick-Disconnect Cables
Communication Cables
Cable
Model Description
Sensor Cables
QDC-515C 4.6 m (15') Cable, straight QD connector
QDC-525C 7.6 m (25') Cable, straight QD connector
QDC-550C 15.2 m (50') Cable, straight QD connector
Communication Cables
MASC 2 m (6.5') DB9, straight RS-232 cable
Control Module Models
