81.0 mm
(3.19")
115.0 mm
(4.53")
106.0 mm
(4.17")
35.0 mm
(1.38")
DIN mounting slot
Slot for M3.5 screws (2) 5.5 mm
(0.22")
69.0 mm
(2.72 ")
5.0 mm
(0.20")
96.0 mm
(3.78")
Figure 2-2. Control module dimensions
