INSTALLATION
INSTRUCTIONS
1270 Instructions 9-15-14.doc Page 1 of 5
2014 – Current Silverado/Sierra Bench Seat Models
Qi Wireless Charging Kit (Kit # FDMC-1270)
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit: Tools & Supplies Needed:
Qi Wireless Charging Module with
Silverado/Sierra Specific Substrate and Mat
Power Harness with 3 amp Fuse
4 – Flat Head Torx 1/2" Screws
These Instructions with Template
Removable Consumer Product Label
Plastic Trim Removal Tool
T-10 Torx Driver
Phillips Screw Driver
Center Punch/Scribe Tool
Power Drill
3/16” and 1/2” Drill Bits
Soldering Iron & Solder (Recommended)
Tape or Heat Shrink Electrical Tubing
*Note this product is designed to work with Qi compatible devices. Please confirm that
your device is Qi compatible before installation. Visit www.brandmotion.com for phone
compatibility guide.
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions.
For additional assistance please call Brandmotion Technical Assistance at (734) 619-1250 then dial 2.
IMPORTANT: Do not place smart keys
within 15cm of charging mat. Vehicle
may not detect key to start vehicle. Do
not place metal objects in tray while
charging.
