Brandmotion 9002-9560-V2 - Manual

INSTALLATION
INSTRUCTIONS
9560 Instructions 7-2-13.doc 1 of 7
Rear Vision System – Aftermarket Display
2007-Current Chevrolet Silverado, Silverado HD; GMC Sierra,
Sierra HD (Kit part number 9002-9560)
Kit Contents:
Chassis Harness with RCA (Note: In some
cases a RCA extension may be required to
connect to your aftermarket display. Kit
#6111 may be purchased at
Brandmotion.com for these cases.)
1 bubble bag containing:
Camera/Module/Tailgate Bezel Assembly
1 bag containing:
Lock Plug (optional)
1 bag containing:
Jumper Harness
1 bag containing:
Template (along with these instructions)
Tools Required:
Socket Wrench
10mm and 13mm Sockets
T15 and T20 Torx Bits
Torque Wrench
Trim Removal Tool
Phillips and Flat Blade Screwdrivers
Delphi Terminal Tool 12094429 or a small flat
blade watch repair screwdriver
Power Drill
25.4mm (1”) Hole Saw
29mm (1-1/8”) Hole Saw
Deburring Tool
Center Punch
Electrical Tape
Vehicle Hoist
Wire Ties (recommended)
Corrosion Inhibitor (recommended)
Note: We strive to provide accurate and up-to-date installation instructions. For the latest full
color instructions, as well as an installation video, please visit www.brandmotion.com
IMPORTANT: Before beginning kit installation, verify kit contents are complete against list above.
