Bird Site Analyzer
66
Recall Trace
When a trace is recalled it is displayed along with the
trace currently being measured. The frequency range
will be changed to the recalled trace’s settings. To
remove a recalled trace from the display, press the
ESCAPE
key from the Save and Recall screen.
☞
NOTE: Calibration is automatically turned off if
the recalled trace has a different frequency range.
From Save
and Recall,
scroll to the
trace to be
recalled
Save and Recall
Save
Recall
Label
Setup
Delete
2 of 2:
001 015 ALPHA RX02 05-OCT-2001 11:26
000 016 BETA TX01 05-OCT-2001 11:26
Reg Description Date
OR
The trace is
recalled 825.00 MHz 841.00
Measure Match Mode
Calibration: Full
1.70
1.00
VSWR
Save/
Recall
Auto
Scale
Limit
Test On
Hold
Print
000, 016 BETA TX0..., 05-OCT-2001 11:26
