97
Chapter 10 Computer Software
The Bird Site Analyzer Software is designed to help
you use the Site Analyzer more effectively. The
software enables use of a PC for archiving and
analyzing measurement data.
Features
y
Multiple Document Interface - allows any number
of trace documents to be open simultaneously.
y
Intelligent drag-and-drop automatically converts
traces to a common scale for precise and reliable
comparisons.
y Documents can be viewed in the frequency or
distance domains, or as a Smith chart.
y Data values can be read off the status bar as the
mouse is moved along the trace.
y Compatible with other cable and antenna testers
including the Bird AT Series.
☞
NOTE: The Bird Site Analyzer and PCTool
software are no longer compatible with trace data
from the Anritsu Site Master.
y
Automatic cursor calibration maintains accurate
readouts of trace data even if the x-axis changes.
y
Supports long file names for easy identification.
Computer Requirements
To install and run the software, your computer system
must meet the following requirements:
y
Windows 95 or later
y
486 or better microprocessor running enhanced
mode (66 MHz or better recommended)
y 1 MB of free memory
y Hard disk with 3 MB of free space
y
1.44 MB Floppy Drive
☞
NOTE: For more instructions refer to the help files
included with the software.
