Measure Match Mode

29

Move

across the

trace

Locate the

highest

point of the

trace

Locate the

lowest point

of the trace

825.00

MHz

841.00

Measure Match Mode

Calibration: Full

M2

M1

M1: 835.20 MHz

M2: 831.50 MHz

∆M: 3.70 MHz

1.64

1.20

0.44

1.70

1.00

V

S

W

R

M1

Active

M2

On

∆M

Single
