PowerFlex® 700S and 700H Frame 12 Replacement Power Structures
23
ASIC Board Connections - Power Structure #1
Note: Refer to
for ASIC Board and Gate Driver Board termination
points.
ASIC Board Connections - Power Structure #2
Connect this component : termination
point . . .
to this component : termination point
ASIC Board: H1 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H1 (fiber optic connector)
ASIC Board: H2 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H2 (fiber optic connector)
ASIC Board: H3 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H3 (fiber optic connector)
ASIC Board: H4 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H4 (fiber optic connector)
ASIC Board: H5 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H5 (fiber optic connector)
ASIC Board: H6 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H6 (fiber optic connector)
ASIC Board: H7 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H7 (fiber optic connector)
ASIC Board: X6
From DC Bus
ASIC Board: X3
Gate Driver Board Power Structure #2: X13
ASIC Board: X4
Gate Driver Board Power Structure #2: X14
ASIC Board: X5
Gate Driver Board Power Structure #2: X15
ASIC Board: H8 (fiber optic connector)
Gate Driver Board Power Structure #2: H4
ASIC Board: H9 (fiber optic connector)
Gate Driver Board Power Structure #2: H5
ASIC Board: H10 (fiber optic connector)
Gate Driver Board Power Structure #2: H6
ASIC Board: H11 (fiber optic connector)
Gate Driver Board Power Structure #2: H7
ASIC Board: H12 (fiber optic connector)
Gate Driver Board Power Structure #2: H8
ASIC Board: H13 (fiber optic connector)
Gate Driver Board Power Structure #2: H9
ASIC Board: X11
Left Fan on Power Structure #2: X8
ASIC Board: X2
Rectifying Board: X13
Connect this component : termination
point . . .
to this component : termination point
ASIC Board: H1 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H11 (fiber optic connector)
ASIC Board: H2 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H12 (fiber optic connector)
ASIC Board: H3 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H13 (fiber optic connector)
ASIC Board: H4 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H14 (fiber optic connector)
ASIC Board: H5 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H15 (fiber optic connector)
ASIC Board: H6 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H16 (fiber optic connector)
ASIC Board: H7 (fiber optic connector)
Star Coupler Fiber Optic Interface Board: H17 (fiber optic connector)
ASIC Board: X6
From DC Bus
ASIC Board: X3
Gate Driver Board Power Structure #1: X13
ASIC Board: X4
Gate Driver Board Power Structure #1: X14
ASIC Board: X5
Gate Driver Board Power Structure #1: X15
ASIC Board: H8 (fiber optic connector)
Gate Driver Board Power Structure #1: H4
ASIC Board: H9 (fiber optic connector)
Gate Driver Board Power Structure #1: H5
ASIC Board: H10 (fiber optic connector)
Gate Driver Board Power Structure #1: H6
ASIC Board: H11 (fiber optic connector)
Gate Driver Board Power Structure #1: H7
ASIC Board: H12 (fiber optic connector)
Gate Driver Board Power Structure #1: H8
ASIC Board: H13 (fiber optic connector)
Gate Driver Board Power Structure #1 : H9
ASIC Board: X11
Left Fan on Power Structure #1 : X8
ASIC Board: X2
Rectifying Board: X13
