8 drive kit options – Rockwell Automation GV3000 AC Pwr Module Ver. 5.0 Hardware Ref, Installation, and Troubleshooting User Manual
Page 32

2Ć16
2.8 Drive Kit Options
Table 2.2 provides a listing of the available GV3000 kit options.
Table 2.2 Ć Available Kits and Options
Kit Description
Option Kit Model Number
Instruction Manual
Snubber Resistor Braking
2SR40400
(1)
2SR40600
(2)
2SR41200
(2)
2SR41800
(3)
D2Ć3291
Low Energy Snubber Braking
Resistor
(1)(2)
2DB4010
2DB4020
D2Ć3179
Snubber Transistor Only
(1)(2)(3)
2ST40027
D2Ć3291
Line Regeneration Unit
(1)(2)(3)
1RG42008
1RG42015
1RG42045
N/A
Motor Encoder Cable
(1)(2)(3)(4)
2TC3025
(5)
2TC3075
(5)
2TC4025
(5)
2TC4075
(5)
2TC4100
(6)
2TC4300
(6)
D2Ć3305
AutoMax Network Communication
Board w/10 Feet of Cable
(1)(2)(3)(4)
2AX3000
D2Ć3308
Remote Meter Interface (RMI)
2SI3000
D2Ć3341
DeviceNet Board
2DV3000
HEĆHGV3DN
Operator Interface Module (OIM)
2RK3000
D2Ć3342
Control and Configuration Software
(CS3000)
2CS3000
D2Ć3348
(1) 1Ć5 HP GV3000 Drives
(2) 7.5Ć10 HP GV3000 Drives
(3) 15Ć60 HP GV3000 Drives
(4) 60Ć150 HP GV3000 Drives
(5) For use with Reliance NEMA Vector Inverter Duty Motors (tachometer connector and exposed wire pairs).
(6) For use with Reliance NEMA Vector Inverter Duty Motors (exposed wire pairs on both ends).
