29 Publication LZ-UM001A-EN-P - January 2008
Chapter
4
Hall Effect Module Removal and Replacement
Introduction Use this section to change the Hall effect module.
Hall Effect Module If a problem is detected with a Hall effect module use the following
procedures to remove and replace the unit.
The following procedures require a 3 mm hex key, non-magnetic preferred,
and cardboard to fit in magnet channel.
Replacement Hall Effect Modules
Remove the Hall Effect Module
1. Disconnect the Hall cable from the drive.
1. Place the cardboard in the magnet channel to prevent tools from
damaging the magnets by limiting the attractive forces.
2. Remove the two M4 SHCS using a 3 mm hex key.
Install the Hall Effect Module
1. Place the cardboard in the magnet channel to prevent tools from
damaging the magnets by limiting the attractive forces.
Topic Page
Hall Effect Module 29
Coil
Catalog No. Winding
Type Hall Effect Module
Part Number
LZ-xxx-x-xxx-D-x-x-xx-x Y B91860
LZ-xxx-x-xxx-E-x-x-xx-x
LZ-xxx-x-xxx-F-x-x-xx-x Delta B91860-Delta
LZ-xxx-x-xxx-G-x-x-xx-x
