Troubleshooting

Introduction

Use this section to diagnose the health of motor coil and the Hall effect
module.

Hall Effect Module

Use the following procedures to troubleshoot the Hall effect module.

Hall Effect Circuit - Hall Signals Test

1. Turn the drive power OFF.

2. Verify the Hall circuit is connected to the drive per interface wiring

specifications.

3. Disconnect the motor leads from the drive.

4. Turn the Hall power supply ON (driver power ON).

5. Using an oscilloscope, while referring to the Motor Phasing Diagram,

check the waveforms at S1, S2 and S3 while slowly and steadily moving
the motor by hand in the specified phasing direction.

Topic

Page

Hall Effect Module

21

PTC Thermal Signal

22

Motor Coil Electrical Test

23

Motor Back EMF Tests

24

Checking the Magnet Channel Butting Polarity

26

ATTENTION

Even with the motor power disabled and leads disconnected,
permanent magnet motors can generate high back EMF voltage
when moving due to external forces.
