Publication LZ-UM001A-EN-P - January 2008
16 Installation
Feedback Cable Signals
ATTENTION
Disconnect the input power supply before installing or servicing
the motor.
The motor lead connections can short and cause damage or
injury if not well secured and insulated.
Insulate the connections, equal to or better than the insulation
on the supply conductors.
Properly ground the motor per the selected drive manual.
Signal Type Color from
Module Signal
Designation Comment
Trapezoidal
Hall
Effect
Circuit Red +V 5-24Vdc Hall Supply, 20 mA.
Black VRTN Hall signal common.
White S1 • Trapezoidal Hall Signals, 120 o
Spacing, Open Collector
Transistor (24Vmax) Outputs
(Pull-up Resistor External).
• Consult the drive manual or
supplier for specific wiring
instructions to the drive.
Wiring is phase-commutation
sensitive.
Blue S2
Orange S3
Shield Silver Brad Cable Shield Terminate at the drive end per the
drive manual instructions.
Thermistor Black
Black TR+
TR- Positive Temperature Coefficient
(PTC) thermistor.
