Part number explanation – Rockwell Automation 20D DC SCR Precharge Module User Manual
Page 9
Overview
P-3
Part Number Explanation
The available ratings for the DC SCR Precharge Module are shown below:
Important: These DC SCR Precharge Modules are available for 380-480
VAC drive applications only.
Module Rating
(DC Amps)
DC SCR Precharge Module Part Number
with Aluminum Heatsink
with Nickel-Plated Heatsink
500A
370696
370724
750A
370711
370729
1000A
370715
370733
1600A
370707
370737
