Preface
Overview
The purpose of this manual is to provide you with the basic information
needed to install, start-up, and troubleshoot the DC SCR Precharge Module.
Who Should Use this
Manual? This manual is intended for personnel qualified in the installation,
programming, and operation of Adjustable Frequency AC Drives and their
use in common DC bus systems.
Installation Requirement The DC SCR Precharge Module must be installed only within the drive’s
enclosure.
Reference Materials The following publications are recommended for general drive information:
Publications can be obtained online at
http://www.rockwellautomation.com/literature .
For information on ... See page ...
Who Should Use this Manual? P-1
Installation Requirement P-1
Reference Materials P-1
Manual Conventions P-2
General Precautions P-2
Part Number Explanation P-3
Description and Block Diagram P-4
Title Publication
Wiring and Grounding Guidelines for Pulse Width Modulated (PWM) AC Drives DRIVES-IN001…
Preventive Maintenance of Industrial Control and Drive System Equipment
DRIVES-TD001
…
Reactors and Isolation Transformers 1321-TD001 …
Safety Guidelines for the Application, Installation and Maintenance of Solid
State Control SGI-1.1
A Global Reference Guide for Reading Schematic Diagrams 0100-2.10
Guarding Against Electrostatic Damage 8000-4.5.2
