8

Rockwell Automation Publication GMC-RM007A-EN-P - September 2011

Kinetix 7000 Drive Systems

In this example, the Kinetix 7000 drive system is shown with the 8720MC Regenerative Power Supply (RPS) in
DC common-bus configuration with two follower 2099-BM11-S drives. Harmonic filter, varistor, and magnetic contactor
are included when ordering the 8720MC-EF190-VB EMC line filter.

In this full-line regenerative example, the 8720MC-RPS190 unit provides motoring power and regenerative braking.

Kinetix 7000 DC Input Power Example (with full-line regeneration)

1606-XL

Power Supply

Input

Allen-Bradley

REGENERATIVE POWER SUPPLY

REGENERATIVE POWER SUPPLY

8720

8720

MC

MC

RST PRG ENT

READY

READY

FAULT

FAULT

PROGRAM

PROGRAM

kW

kW

V

A

1606-XL

Power Supply

Input

Allen-Bradley

REGENERATIVE POWER SUPPLY

8720

8720

MC

MC

RST PRG ENT

READY

READY

FAUL

FAULT

PROGRAM

PROGRAM

kW

kW

V

A

DC Bus

Kinetix 7000 Drive

2099-BM11-S

Common Bus Follower

Regenerative Power Supply
8720MC-RPS190-BM
Common Bus Leader

Line Reactor
8720MC-LR10-100B
(two units in parallel)

Three-phase
Input Power

EMC Line Filter 8720MC-EF190-VB
This unit includes an AC line filter (required for CE),
magnetic contactor, harmonic filter, and varistor.

IMPORTANT The Bulletin 8720MC line filter unit and
line reactor are required when using the
8720MC-RPS190 regenerative power supply.

Input
Fusing

Full Regenerative

Kinetix 7000 Drive

2099-BM11-S

Common Bus Follower

24V DC

Control Power

1606-XL

xxx

24V DC

Control Power

1606-XL

xxx

HPK-Series Asynchronous

Servo Motors

DC Bus

Fusing

DC Bus

Fusing

Control Power

Supply Input

Control Power

Supply Input

MP-Series (Bulletin MPL or MPM)

and RDD-Series Servo Motors
