18 Rockwell Automation Publication GMC-RM007A-EN-P - September 2011
Kinetix 7000 Drive Systems
Bulletin MPL Motor Performance Specifications with Kinetix 7000 (400V class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software, version 4.7 or later.
Rotary Motor
Speed, max
rpm
System Continuous
Stall Current
A 0-pk System Continuous
Stall Torque
N•m (lb•in) System Peak
Stall Current
A 0-pk System Peak
Stall Torque
N•m (lb•in) Motor Rated
Output
kW
Kinetix 7000
(400V class) Drives
MPL-B540K 3000 20.4 19.5 (172) 60.0 48.6 (430) 5.4 2099-BM06-S
MPL-B560F 3000 20.6 27.0 (239) 68.0 67.7 (599) 5.5 2099-BM06-S
MPL-B580F 3000 26.0 34.0 (301) 94.0 87.0 (770) 7.1 2099-BM06-S
MPL-B580J 3800 32.0 34.0 (301) 94.0 81.0 (717) 7.9 2099-BM06-S
MPL-B640F 3000 27.8 36.7 (325) 65.0 72.3 (640) 6.1 2099-BM06-S
MPL-B660F 3000 33.0 48.0 (425) 96.0 101 (894) 6.1 2099-BM06-S
MPL-B680D 2000 29.4 62.8 (556) 94.0 154 (1363) 9.3 2099-BM06-S
MPL-B680F 3000 41.5 59.4 (526) 96.0 108 (956) 7.5 2099-BM06-S
MPL-B860D 2000 40.9 83.1 (735) 95.5 152 (1345) 12.5 2099-BM06-S
MPL-B880C 1500 41.1
108 (956) 96.0 200 (1796)
12.6
2099-BM06-S
109 (965) 97.5 203 (1770) 2099-BM07-S
MPL-B880D 2000
57.0 92.5 (818)
96.0 147 (1301) 12.6
2099-BM06-S
58.0 110 (973) 2099-BM07-S
MPL-B960B 1200 36.8 130 (1150) 94.0 231 (2044) 12.7 2099-BM06-S
MPL-B960C 1500 47.6 124 (1097)
96.0 184 (1628)
14.8
2099-BM06-S
113 209 (1850) 2099-BM07-S
125 226 (2000) 2099-BM08-S
MPL-B960D 2000
57.0 100 (885) 96.0 171 (1513)
15.0
2099-BM06-S
60.6 124 (1097)
113 201 (1779) 2099-BM07-S
125 223 (1973) 2099-BM08-S
MPL-B980B 1000 34.6 162 (1434) 94.0 278 (2460) 15.2 2099-BM06-S
MPL-B980C 1500
57.0 131 (1159) 96.0 198 (1752)
16.8
2099-BM06-S
59.0 158 (1398)
113 227 (2009) 2099-BM07-S
140 270 (2389) 2099-BM08-S
MPL-B980D 2000
57.0 113 (1000) 96.0 183 (1619)
18.6
2099-BM06-S
68.4
148 (1310) 113 213 (1885) 2099-BM07-S
158 (1398) 140 259 (2292) 2099-BM08-S
MPL-B980E 2750 105 141 (1250) 218 237 (2100) 13.0 2099-BM09-S
