Rockwell Automation Publication GMC-RM007A-EN-P - September 2011

17

Kinetix 7000 Drive Systems

Kinetix 7000 (400V class) Drives with MP-Series Low Inertia Motors

This section provides system combination information for the Kinetix 7000 (400V class) drives when matched with
MP-Series™ low-inertia motors. Included are motor power/brake and feedback cable catalog numbers, system performance
specifications, and the optimum torque/speed curves.

Bulletin MPL Motor Cable Combinations

For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on

page 9

.

Motor-end connector kits, and panel-mounted breakout components (drive end), are available for motor power/brake and feedback cables. Refer to 2090-Series Motor/Actuator Cables Overview on

page 9

.

Cable length

xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publication

GMC-TD004

, for standard cable lengths.

IMPORTANT

The MP-Series low-inertia motors on this page are equipped with DIN connectors (specified by 7 in the catalog number) and are
not compatible with cables designed for motors equipped with bayonet connectors (specified by 2 in the catalog number). The
motors with bayonet connectors (for example, MPL-A310P-

xx2xAA) are being discontinued and require 2090-XXNxMP (bayonet)

cables. For help with migration or to select bayonet cables, contact your Rockwell Automation® sales representative.

Motor Cat. No. (400V class)

Motor Power/Brake Cable

Motor Feedback Cable

(1)

(1) Use low-profile connector kit (catalog number 2090-K6CK-D15M) or panel-mounted breakout components on drive end. Refer to Required Drive Accessories on

page 3

.

MPL-B540K

-xx7xAA, MPL-B560F-xx7xAA

2090-CP

xM7DF-14AAxx (standard, non-flex)

2090-CP

xM7DF-14AFxx (continuous-flex)

2090-CFBM7DF-CEAA

xx or

2090-CFBM7DD-CEAA

xx (standard, non-flex)

2090-CFBM7DF-CEAF

xx or

2090-CFBM7DD-CEAF

xx (continuous-flex)

Absolute High-resolution Feedback

MPL-B580F

-xx7xAA, MPL-B580J-xx7xAA

MPL-B640F

-xx7xAA

2090-CP

xM7DF-10AAxx (standard, non-flex)

2090-CP

xM7DF-10AFxx (continuous-flex)

MPL-B660F

-xx7xAA, MPL-B680D-xx7xAA,

MPL-B960B

-xx7xAA, MPL-B980B-xx7xAA

2090-CP

xM7DF-08AAxx (standard, non-flex)

2090-CP

xM7DF-08AFxx (continuous-flex)

MPL-B680F

-xx7xAA, MPL-B860D-xx7xAA

2090-CPBM7DF-06AA

xx (standard, non-flex)

MPL-B880C

-xx7xAA

MPL-B880D

-xx7xAA

2090-CPBM7DF-04AA

xx (standard, non-flex)

MPL-B960C

-xx7xAA, MPL-B960D-xx7xAA,

MPL-B980C

-xx7xAA, MPL-B980D-xx7xAA

MPL-B980E

-xx7xAA

2090-CPBM7DF-02AA

xx (standard, non-flex)
