Rockwell Automation Publication GMC-RM007A-EN-P - September 2011

27

Kinetix 7000 Drive Systems

Kinetix 7000 Drives with RDD-Series Direct Drive Motors

This section provides system combination information for the Kinetix 7000 (400V class) drives when matched with
RDD-Series™ direct-drive motors. Included are motor power/brake and feedback cable catalog numbers, system
performance specifications, and the optimum torque/speed curves.

Bulletin RDB Motor Cable Combinations

For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on

page 9

.

Motor-end connector kits (drive end) are available for motor power/brake and feedback cables. Refer to 2090-Series Motor/Actuator Cables Overview on

page 9

.

Cable length

xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publication

GMC-TD004

, for standard cable lengths.

Bulletin RDB Motor Performance Specifications with Kinetix 7000 (400V class) Drives

Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software, version 4.7 or later.

Motor Cat. No. (400V class)

Motor Power/Brake Cable

Motor Feedback Cable

(1)

(1) Use low-profile feedback module (catalog number 2090-K7CK-KENDAT). Refer to Required Drive Accessories on

page 3

.

RDB-B2152C

2090-CPWM7DF-12AA

xx (standard, non-flex)

2090-XXNFMF-S

xx (standard, non-flex)

2090-CFBM7DF-CDAF

xx (continuous-flex)

Absolute High-resolution Feedback

RDB-B2153C, RDB-B29036

2090-CPWM7DF-10AA

xx (standard, non-flex)

2090-CPWM7DF-10AF

xx (continuous-flex)

RDB-B29029, RDB-B41016, RDB-B41024

2090-CPWM7DF-08AA

xx (standard, non-flex)

2090-CPWM7DF-08AF

xx (continuous-flex)

RDB-B29039, RDB-B41018, RDB-B41026, RDB-B41035

2090-CPBM7DF-06AA

xx (standard, non-flex)

Rotary Motor

Speed,
base
rpm

Speed,
max
rpm

System Continuous
Stall Current
A 0-pk

System Continuous
Stall Torque
N•m (lb•in)

System Peak
Stall Current
A 0-pk

System Peak
Stall Torque
N•m (lb•in)

Motor Rated
Output
kW

Kinetix 7000
(400V class) Drives

RDB-B2152C

1500

2125

23.5

43.4 (384)

63.2

111 (982)

6.41

2099-BM06-S

RDB-B2153C

1500

2250

29.4

51.5 (456)

82.6

137 (1212)

5.87

2099-BM06-S

RDB-B29029

750

1200

36.2

97.5 (863)

96.0

193 (1708)

4.05

2099-BM06-S

111

214 (1894)

2099-BM07-S

RDB-B29036

375

750

26.0

140 (1239)

84.9

318 (2814)

5.49

2099-BM06-S

RDB-B29039

750

1000

52.7

122 (1080)

147

268 (2372)

4.41

2099-BM08-S

RDB-B41016

375

700

33.2

183 (1619)

95.5

339 (3000)

4.83

2099-BM06-S

RDB-B41018

625

700

51.3

183 (1619)

113

299 (2646)

4.83

2099-BM07-S

140

339 (3000)

2099-BM08-S

RDB-B41024

200

365

31.5

330 (2929)

95.5

690 (6107)

7.29

2099-BM06-S

RDB-B41026

375

600

52.0

308 (2726)

147

626 (5540)

7.29

2099-BM08-S

218

688 (6089)

2099-BM09-S

RDB-B41035

250

490

52.6

425 (3761)

147

897 (7939)

8.69

2099-BM08-S

218

1050 (9293)

2099-BM09-S
