Configure the Controller Application Chapter 1
Follow These Steps
The following tasks outlined below describe how to configure your template with a Logix5000 controller. You could
already be familiar with many of these tasks, depending on your knowledge of Logix controllers. However, we suggest that
you follow these steps to set up your controller for optimal performance of your PlantPAx system.
The procedures in this chapter have to be completed for each controller in your project.
Start
Download the PlantPAx Library
on page 13
Open Your Template
on page 13
Modify Controller Properties
on page 14
Configure Controller Task Rates
on page 16
Add Modules to Local Chassis
on page 17
Configure Network Adapters
on page 18
Configure I/O Modules
on page 19
Add Remote I/O Chassis and Modules
on page 20
Download the Project
on page 21
