ControlNet Message/Traffic Generator Tool 7
Publication 9220-10.1 — July 1996
Using the Tool
This figure shows the functional blocks for navigation through the tool,
with each block representing a single window.
Send Unconnected
Messages Open
Connections Send Connected
Messages
Status
Display
Traffic Generator
Main Menu
Data Repeater Data Patterns Data Bytes
For information on See page
changing the network update time 8
changing the port number of the 9220-KTCT card 8
changing the MAC ID of the 9220-KTCT card 9
viewing the tool’s current status 9
sending a message to a target node 10
sending an unconnected message 13
closing a connection 14
using the traffic generator 15
taking the card offline 18
exiting the tool 18
editing the tool’s configuration file 19
