Determining cable lengths – Rockwell Automation 2500 CENTERLINE Motor Control Centers Installation Manual User Manual
Page 79
Rockwell Automation Publication 2500-IN001C-EN-P - April 2014
79
IntelliCENTER Options
Chapter 9
Figure 26 - EtherNet/IP Network Connections in 2500 MCC Units
Determining Cable Lengths
To help determine cable lengths for your application, each MCC is shipped with
documentation identifying the cable length used within the MCC.
Ethernet cable
enters and leaves
through wireways on
each side of column.
Removable horizontal
wireway cover at top
of MCC column.
NOTE: Examples above depict typical 2500 MCC configurations with EtherNet/IP communication.
Refer to
for more information on EtherNet/IP communication for 2500 MCC units.
Refer to
for more information on Stratix 5700 Ethernet-managed switches.
Ethernet cable routing through
typical single MCC column.
Stratix 5700
Ethernet Ports
(6 port
model shown)
Ethernet cable routing through typical two MCC columns.
Stratix 5700 switch behind top horizontal wireway cover.
