Rockwell Automation 8720MC 8720MC Regenerative Power Supply User Manual User Manual
Page 35
Figure 3.3
Required Distance between Units in Case of Two Paralleled Units of
Model 8720MC-RPS027 or 8720MC-RPS065 Units
Figure 3.4
Required Distance between Units in Case of Three Paralleled Units of
Model 8720MC-RPS027 or 8720MC-RPS065 Units
3-5
Installation
Max. 250 (9.8)
Max. 250 (9.8)
Unit: Millimeter (Inch)
REGENERATIVE POWER SUPPLY
REGENERATIVE POWER SUPPLY
8720
MC
MC
RST PRG ENT
READY
FAULT
PROGRAM
kW
V
A
REGENERATIVE POWER SUPPLY
REGENERATIVE POWER SUPPLY
8720
MC
MC
REGENERATIVE POWER SUPPLY
REGENERATIVE POWER SUPPLY
8720
MC
MC
Note: In case three units of Model 8720MC-RPS027 or 8720MC-RPS065 unit are installed in parallel,
the master unit must be installed at the rightmost end as shown in the above.
Max. 250 (9.8)
Unit: Millimeter (Inch)
REGENERATIVE POWER SUPPLY
REGENERATIVE POWER SUPPLY
8720
8720
MC
RST PRG ENT
READY
READY
FAULT
FAULT
PROGRAM
PROGRAM
kW
kW
V
A
REGENERATIVE POWER SUPPLY
REGENERATIVE POWER SUPPLY
8720
8720
MC
Note: In case two units of Model 8720MC-RPS027 or 8720MC-RPS065 unit are installed in parallel,
the master unit must be on the right hand side as shown in the above.
