A–38 Application Examples
Publication 2755-6.6
5. Scan the Parity bar code.
Even
The cable defaults work with the DTAM Plus Operator Interface.
Your application may have specific requirements. If you change a
communication setting, make sure the DTAM Plus Operator
Interface is configured to accept the change.
DTAM Plus Operator Interface Setup
You may need to configure the DTAM Plus Operator Interface
RS-232 port to accept the scanner data. Follow the steps below or
refer to the DTAM Programming Software Programming Manual
(Publication No. 2707-802).
1. Open Screen Builder.
2. Open Create Screen.
3. Open Data Entry Screen.
4. Select Set Up Screen.
5. Select Data Entry.
6. Select ASCII Input.
7. Set up DTAM.
