Rockwell Automation 2755 Hand-Held Cordless Bar Code Scanners User Manual
Page 152
Application Examples
A–35
Publication 2755-6.6
Hardware Connections for the DTAM Plus Operator Interface
The scanners connect to the DTAM Plus Operator Interface with the
RS-232 cable (Catalog No. 2755-HCC-BR1-06). You need to use a
25–9 pin connector as shown below.
RS-232C Cable
Base/Charger Unit
Power Supply
To Power
Receptacle
25–9 Pin
Adapter
PLC-5 Controller
1771-SDN Module
DTAM Plus DeviceNet
