Rockwell Automation 2755 Hand-Held Cordless Bar Code Scanners User Manual
Page 120
Application Examples
A–3
Publication 2755-6.6
Hardware Connections for AUX Port Pass-Through
The base/charger unit connects to an input port on the enhanced
decoder with an RS-232 cable (Catalog No. 2755-HCC-BR1-06).
To Enhanced Decoder
RS-232C Cable
Base/Charger Unit
Power Supply
To Power Receptacle
Enhanced Decoder
