22 PanelView 300 Micro Terminal
41061-156-01(A)
Maintenance
The PanelView 300 Micro has no internal components that are user accessible.
The rear cover is not removable, therefore, you should not remove it for
troubleshooting or maintenance. The real-time clock battery and the LCD display
backlight are not replaceable.
To clean the display window of the PanelView 300 Micro:
1. Disconnect power from the terminal at the power source.
2. Use a clean sponge or soft cloth to clean with a mild soap or detergent to clean
the display. Do not scrub, use brushes, abrasive cleaners or solvents.
3. Dry the display with a chamois or moist cellulose sponge to avoid water spots.
Accessories
The following accessories are available for the PanelView 300 Micro.
PanelBuilder32 Software
DC Power Input Terminal Block
Communication Cables
Catalog No. Description Version
2711-ND3 PanelBuilder32 Software for developing applications
for the line of Standard PanelView terminals. 3.60 or later
Catalog No. Description Quantity
2711-TBDC Removable (3-position screw) DC Power Input Terminal Block 10
Cable Connector Type Cable Length
1761-CBL-AM00, Series C 8-pin mini-DIN to 8-pin mini-DIN 0.5 meter (1.5 ft)
1761-CBL-AP00, Series C 8-pin mini-DIN to 9-pin D-Shell 0.5 meter (1.5 ft)
1761-CBL-PM02, Series C 8-pin mini-DIN to 9-pin D-Shell 2 meter (6.5 ft)
1761-CBL-HM02, Series C 8-pin mini-DIN to 8-pin mini-DIN 2 meter (6.5 ft)
2711-CBL-PM05, Series C 8-pin mini-DIN to 9-pin D-Shell 5 meter (15 ft)
2711-CBL-HM05, Series C 8-pin mini-DIN to 8-pin mini-DIN 5 meter (15 ft)
2711-CBL-PM10, Series C 8-pin mini-DIN to 9-pin D-Shell 10 meter (30 ft)
2711-CBL-HM10, Series C 8-pin mini-DIN to 8-pin mini-DIN 10 meter (30 ft)
