Page 187: Appendix
Appendix
C
Publication 2711E-6.15 – November 1998
Arrows and Parts
This appendix lists the graphic images of arrows and equipment parts
provided with PanelBuilder 1400e. If you followed the default
installation, they are in the \IMAGES\ARROWS and
IMAGES\PARTS directories.
You can use any monochrome image as a Symbol object, including
some of these bitmaps of arrows (the first eight arrows are not
monochrome). You can also use these bitmaps as graphic images.
The images are presented alphabetically by file name in the tables
that follow, to match the order in which they are listed in the Select
Image and Select Symbol dialog boxes.
File Name
Arrow Shape
File Name
Arrow Shape
Arrows
