Page 9: Introduction to the panelview plus ce terminal, Chapter, Functional block diagram
9
Publication 2711P-UM005A-EN-P - March 2007
Chapter
1
Introduction to the PanelView Plus CE
Terminal
This chapter provides an overview of the PanelView Plus CE
terminals, including the hardware and software architecture.
Hardware Architecture
Functional Block Diagram
GMCH
FW82810E
ICH2
FW82801BA
CPU
Celeron
mlCP 650 MHz ULV
Firmware Hub
SST49LF008A
Super IO
SMSC
LPC47N267
F
S
B
100
M
H
z
ICH2
HUB
B
u
s
LP
C
B
us
2xUSB
connector
AGP
connector
USB bus
PCI bus 33 MHz
COM1
IrDA
CPLD
LCD
Interface
Compact flash
AC97 Audio
256 MB
SODIM
Atmel
MEGA128
or
MEGA64
Touch
interface
Key
Scan
LED's
LAN interface
82562ET
RTC
5Volts in
Power Supplies
CPU core
1.1V
CPU I/O
1.25V
1.8V
Primary IDE
AC97 interface
Removable
Compact
Flash
Dual
PC card
Controller
PCI1225
D
is
p
la
y
Int
er
fa
c
e
C
onnect
o
rs
I2C Bus
Third USB Port
3.3V
Analog VGA interface
Backlight
PWM and
GP I/O's
USB Port 4
UART
XB
u
s
