Kinetix 3 Component Servo Drives 9
Publication 2071-IN001E-EN-P - August 2014
Analog Output (A.out) Connector
A.out Pin Description Signal
1 Analog output #1 AOUT1
2 Analog output #1 ground ACOM
3 Analog output #2 AOUT2
4 Analog output #2 ground ACOM
Input Power (IPD) Connector
IPD Pin Description Signal
L1 Main AC power L1
L2 Main AC power L2
L3 Main AC power (1) L3
L1C L1C - Control power L1C
L2C L2C - Control power L2C
DC DC bus negative DC- (not supported)
(1) L3 is not used for single phase drives.
Shunt Power (BC) Connector
BC Pin Description Signal
B1
Shunt resistor +
DC bus positive B1
(not supported)
B2 Shunt resistor - B2
Motor-Power (MP) Connector
MP Pin Description Signal
U Motor power U U
V Motor power V V
W Motor power W W
