Rockwell Automation 2071-Axx Kinetix 3 Component Servo Drive User Manual
Page 7
Kinetix 3 Component Servo Drives 7
Publication 2071-IN001E-EN-P - August 2014
Catalog Numbers 2071-AP8, 2071-A10, and 2071-A15
Dimensions are in millimeters (inches). Drives are designed to metric dimensions; inches are a mathematical conversion.
155.0
(6.11)
198.6
(7.82)
186.2
(7.34)
81.0
(3.19)
50.0
(1.97)
59.0
(2.32)
145.0
(5.71)
5.0
(0.2)
Mounting hole (top) and slot
(bottom) require M5 x 10 bolts.
Chassis Ground
Terminals (2)
