Kinetix 3 Component Servo Drives 3
Publication 2071-IN001E-EN-P - August 2014
Catalog Number Explanation
This publication applies to the following Kinetix 3 drives.
Before You Begin
Remove all packing materials, wedges, and braces from within and around the components.
After unpacking, check the item nameplate catalog number against the purchase order.
Safety Information
Cat. No. Input Voltage Continuous Output Power
Continuous Output Current
(0-pk)
2071-AP0
240V AC rms, 1 Ø
50 W 0.85 A
2071-AP1 100 W 1.56 A
2071-AP2 200 W 2.40 A
2071-AP4 400 W 4.67 A
2071-AP8 240V AC rms, 1 Ø or 3 Ø 800 W 7.07 A
2071-A10
220V AC rms, 3 Ø
1.0 kW 9.90 A
2071-A15 1.5 kW 13.99 A
SHOCK HAZARD: Capacitors retain charge for approximately 300 s after power is removed.
Disconnect incoming power and wait at least five minutes before touching the drive. There is a
status indicator on the front of the drive that shows there is charge on the capacitors. Failure to
observe this precaution could result in severe bodily injury or loss of life.
WARNING: The opening of branch-circuit protective device can be an indication that a fault has
been interrupted. To reduce the risk of fire or electric shock, parts that carry current and other
components of the controller must be examined and replaced if damaged.
