Chapter 2 Create a PanelView Plus Project
Numeric Display Objects
In this section, you will learn how to create and configure numeric display objects. This object is used to display the value of
a counter variable (CV) or a project variable (PV).
1. Create numeric display objects
(CV and PV) on your
application screen as shown in
the example above. To configure
each object, right-click the
object and select Properties.
A Numeric Display Properties
window appears.
Under the General tab, you can
modify the look of the object. If
you make any changes, click
Apply after you have finished.
CV Display objects PV Display objects
