Create a PanelView Plus Project Chapter 2
Example of PanelView Plus Application in FactoryTalk View Machine Edition
Two types of objects are used in this example – numeric display object
and momentary push button object
. To
learn how to create these objects, see the respective sections below.
1.
Numeric Display Objects on page 22
a. CV Display Object
b. PV Display Object
2.
Momentary Push Button Objects on page 28
a. Key Press Button
b. Reset Counter Button
c. Copy CV to PV Button
2a
1a
1b
2b
2c
