Chapter 6
Slave Mode Operation / Examples
6–13
1025 LN=48: ADDRESS = 1: M$ = ’’ ’’: REM THIS TURNS ON THE DL50‘s RELAY
1026 RETURN
1030 LN=49: ADDRESS = 127: M$ = ’’ ’’: REM THIS TURNS OFF THE DL50‘s RELAY
1031 RETURN
1035 LN=50: ADDRESS = 127: M$ = ’’ ’’: REM THIS CLEARS THe DL50 DISPLAY
1036 RETURN
2000 RETURN
4000 REM LINE 4000-6000 DETERMINE IF ANY ALARMS ARE CURRENT AND WHICH
4001 REM ONE HAS PRIORITY
4002 REM
4030 INPUT “Alarm No.”; ALARM: REM ###THIS IS FOR PROGRAM TEST ONLY###
4040 IF ALARM=0 THEN END: REM ###THIS LINE IS FOR PROGRAM TEST ONLY###
4050 REM THE USER PLACES LINES OF CODE FOR ALARM HANDLING HERE
6000 RETURN
9000 REM DISPLAY THE MENU OF TEST MESSAGES
9001 REM ###THESE LINES FOR PROGRAM TEST ONLY###
9005 PRINT “ALARM # Sent to Line # Result at Dl50 (in Auto-Select Mode)
9006 PRINT “_______ ___________ ____________________________”
9110 PRINT “ 1 1 ’ TEST ALARM # 1 ’ ”
9115 PRINT “ 2 2 ’ TEST ALARM #2 ’ ”
9120 PRINT “ 3 3 ’ ALARM #3 ’ (Large Characters) ”
9125 PRINT “ 4 30 ’ THIS IS A TWO-LINE ’ (Lines 1 & 2) ”
9130 PRINT “ TEST ALARM #4 ’ ”
9135 PRINT “ 5 48 * THIS TURNS ON THE DL50) RELAY * ”
9140 PRINT “ 6 49 * THIS TURNS OFF THE DL50) RELAY * ”
9145 PRINT “ 7 30 * THIS CLEARS THE DL50) DISPLAY * ”
9150 PRINT “ 8 ** UNUSED ** ’ ”
9155 PRINT “ 9 ** REPEATS THIS MENU AGAIN ** ”
9160 PRINT “ 0 ** QUITS THE PROGRAM ** ”
9165 PRINT “
9200 RETURN
Using the DL50 ALARM BASIC Program
After entering the program, the program will prompt to enter an alarm
number. Press any key 0 through 7 and then the Return key. Refer to program
lines 9000 through 9160 for a description of each alarm function. Press 0 and
Return to exit the program.
Note: You can also use this program in a PLC/SLC BASIC Module with the
changes described on the following page.
