Rockwell Automation 1792D-4BV4D ArmorBlock MaXum 4 Input/4 Output Module with 8 Connectors, Series B I.I. User Manual
Page 15
ArmorBlock MaXum 4 Input / 4 Output Module with 8 Connectors, Series B 15
Publication 1792D-IN050A-EN-P - February 2001
General Specifications
Auxiliary Power Voltage
Current
30V dc max
4A max
10V dc min
4A max
Dimensions (assembled to base)
inches - (Millimeters)
1.9H x 2.7W x 6.85D
(48.26)H x (68.6)W x (174)D (millimeters)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
Non-operating
Vibration
-25 to 60
o
(-13 to 140
o
F)
-25 to 80
o
C (-13 to 176
O
F)
5 to 100%
30g peak acceleration, 11 (+1) ms pulse width
50g peak acceleration, 11(+1)ms pulse width
Tested 10g @ 10-500Hz per IEC 68-2-6
Conductors
Publication 889-CP001A-US-P
Enclosure
Meets or exceeds IP67
Agency Certification (when
product is marked)
CSA certified
CSA Class I, Division 2, Groups A, B, C, D certified
UL listed
CE marked for all applicable directives
Technical Data (user information)
Publication 1792-TD001B-EN-P
4 Input / 4 Output Module - Cat. No. 1792D-4BV4D
