22 Compact I/O Thermocouple/mV Input Module
Publication 1769-IN026C-EN-P - February 2010
Vibration, operating
10…500 Hz, 5 g, 0.030 in. peak-to-peak
Relay operation 2 g
(1)
Shock, operating
30 g, 11 ms panel-mounted (20 g, 11 ms DIN rail-mounted)
Relay operation 7.5 g panel-mounted (5 g DIN rail-mounted)
Shock, nonoperating
40 g panel-mounted (30 g DIN rail-mounted)
Radiated and conducted emissions
EN50081-2 Class A
Electrical/EMC
The module has passed testing at these levels:
• ESD immunity (IEC61000-4-2)
• 4 kV contact, 8 kV air, 4 kV indirect
• Radiated immunity (IEC61000-4-3)
• 10V/m, 80…1000 MHz, 80% amplitude modulation,
900 MHz keyed carrier
• Fast transient burst (IEC61000-4-4)
• 2 kV, 5 kHz
• Surge immunity (IEC61000-4-5)
• 1 kV galvanic gun
• Conducted immunity (IEC1000-4-6)
• 10V, 0.15…80 MHz
(2)
(3)
(1)
When used with the 1769-OW8 or 1769-OW8I relay output modules.
(2)
Conducted immunity frequency range may be 150 kHz…30 MHz if the radiated immunity frequency range is 30…1000 MHz.
(3)
For grounded thermocouples, the 10V level is reduced to 3V.
Certifications - 1769-IT6
Certification
(1)
(1)
When marked. See the Product Certification link at
for Declarations of Conformity, Certificates, and
other certification details.
1769-IT6
Hazardous environment class
Class I, Division 2, Hazardous Location, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 No. 213)
c-UL
Certified (under CSA C22.2 No. 142)
UL 508 listed
CE
Compliant for all application directives
Calibrated Accuracy - 1769-IT6
Input Type
(1)
Accuracy for 10 Hz, 50 Hz, and 60 Hz Filters
(2)
(max)
@ 25 °C (77 °F)
@ 0…60 °C (32…140 °F)
Thermocouple J (-210…1200 °C (-346…2192 °F))
±0.6 °C (±1.1 °F)
±0.9 °C (±1.6 °F)
Thermocouple N (-200…1300 °C (-328…2372 °F))
±1 °C (±1.8 °F)
±1.5 °C (±2.7 °F)
Thermocouple N (-210…-200 °C (-346…-328 °F))
±1.2 °C (±2.2 °F)
±1.8 °C (±3.2 °F)
Thermocouple T (-230…400 °C (-382…752 °F))
±1 °C (±1.8 °F)
±1.5 °C (±2.7 °F)
Thermocouple T (-270…-230 °C (-454…-382 °F))
±5.4 °C (±9.7 °F)
±7.0 °C (±12.6 °F)
Environmental Specifications - 1769-IT6
Attribute
1769-IT6
