18 Compact I/O Thermocouple/mV Input Module

Publication 1769-IN026C-EN-P - February 2010

Configuration Data File

During initial system configuration, you normally manipulate the bits from the configuration
data file with programming software, such as RSLogix 500 or RSNetWorx for DeviceNet
software. Graphical screens simplify configuration. However, some products, like the
1769-ADN DeviceNet adapter, also let you alter the bits as part of the control program, by
using communication rungs. In this case, you need to understand the bit arrangement. Refer
to the Compact Thermocouple/mV Input Module User Manual, publication

1769-UM004

,

for additional details.
Words 0…5 of the configuration data file let you change the parameters of each channel
independently. For example, word 0 corresponds to channel 0. See the functional
arrangement of the bits for a single word/channel in the

Configuration Data File on page 19

.
