Compact 1769-OF4VI Isolated Analog Output Module 23
Rockwell Automation Publication 1769-IN076B-EN-P - August 2010
Full Scale Analog Ranges
(2)
± 10.5V dc, -0.5 to 10.5V dc, -0.5 to 5.25V dc,
0.5 to 5.25V dc
Number of Outputs 4 isolated differential
Bus Current Draw (max.) 5V, 165mA
24V, 110mA
Heat Dissipation 2.0 Total Watts (all points - 10V dc into 2 k - worst
case calculated)
Digital Resolution Across Full Range 15 bits plus sign (bipolar)
±10V dc: 15.89 bits, 330 µV/bit
0 to +5V dc: 13.89 bits, 330 µV/bit
0 to +10V dc: 14.89 bits, 330 µV/bit
+1 to +5V dc: 13.57 bits, 330 µV/bit
Conversion Rate (all channels) max. 120 ms
Step Response to 63%
(3)
<2.9 ms
Load Output Current 5 mA max.
Load Range Output > 2K
Ω
Max. Capacitive Load 1 µF
Field Calibration None required
Overall Accuracy
(4)
±0.5% full scale at 25°C
(1) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency
range is 30 MHz to 1000 MHz.
(2) The over- or under-range flag will come on when the normal operating range (over/under) is
exceeded. The module will continue to convert the analog output up to the maximum full scale range.
The flag automatically resets when within the normal operating range unless configured to latch.
(3) Step response is the period of time between when the D/A converter was instructed to go from
minimum to full range until the device is at 63% of full range.
(4) Includes offset, gain, drift, non-linearity and repeatability error terms.
Specification 1769-OF4VI
