22 Compact 1769-OF4VI Isolated Analog Output Module
Rockwell Automation Publication 1769-IN076B-EN-P - August 2010
Specifications
Specification 1769-OF4VI
Dimensions 118 mm (height) x 87 mm (depth) x 35 mm (width)
height including mounting tabs is 138 mm
4.65 in. (height) x 3.43 in (depth) x 1.38 in (width)
height including mounting tabs is 5.43 in.
Approximate Shipping Weight
(with carton) 270g (0.6 lbs.)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Temperature 0°C to +60°C (32°F to +140°F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude 2000 meters (6561 feet)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak
Shock Operating: 30G, 11 ms panel mounted
(20G, 11 ms DIN rail mounted)
Non-Operating: 40G panel mounted
(30G DIN rail mounted)
Agency Certification •C-UL certified (under CSA C22.2 No. 142)
•UL 508 listed
•CE compliant for all applicable directives
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B,
C, D (ISA 12.12-01, C-UL under CSA C22.2 No. 213)
Radiated and Conducted Emissions IEC 61000-6-4 and CISPR 11 Group 1, class A
Electrical /EMC: The module has passed testing at the following
levels:
•ESD Immunity (IEC 61000-4-2) •4 kV contact, 8 kV air, 4 kV indirect
•Radiated Immunity (IEC
61000-4-3)
•10 V/m, 80 to 1000 MHz, 80% amplitude
modulation
•Fast Transient Burst (IEC
61000-4-4)
•2 kV, 5 kHz
•Surge Immunity (IEC 61000-4-5) •1 kV galvanic gun
•Conducted Immunity (IEC
61000-4-6)
• 10V dc, 0.15 to 80 MHz
(1)
Analog Normal Operating Ranges
(2)
± 10V dc, 0 to 10V dc, 0 to 5V dc, 1 to 5V dc
