Pico GFX Control Commands 7-61
Timing relays: T01 – T32
Table 6.189 Index 0 – Bit IO
Bit 7 6 5 4 3 2 1 0
FB output Data 3 – – – – – – –
EN
(1)
(1) Activates the function block on status 1.
Table 6.190 Telegram Structure
Byte Meaning Value (hex), sent by
Master Slave Master Slave
Attribute ID
Read 92 –
Write B2 –
0 Response:
Read successful – C2
Write successful – C1
Command
rejected – C0
0 1 Type 21 21
1 2 Instance 01 – 20 01 – 20
2 3 Index Table 6.191 Table 6.191
3 – 6 4 – 7 Data 1 – 4
Read operation 00 depending on index,
Table 6.192, 6.193
Write operation depending on index,
Table 6.192, 6.193
Table 6.191 Operand overview
Index
(hex) Operand read write
00 Bit IO, Table 6.192 x
01 Mode/Parameters, Table 6.193 x
