Specifications Appendix A
Output Specifications
Attribute Value
Analog normal operating ranges
(1) ±10V DC
0…10V DC 0…5V DC
1…5V DC 0…20 mA
4…20 mA
Full scale analog ranges
(1) ±10.5V DC
-0.5…10.5V DC -0.5…5.25V DC
0.5…5.25V DC 0…21 mA
3.2…21 mA
Number of outputs Two single-ended
Digital resolution across full range 13 bits unipolar, 13 bits plus sign bipolar
Conversion rate (all channels) max 1 ms
Step response to 63%
(2) 2.0 ms
Resistive load, current 0…500
Ω
(includes wire resistance)
Resistive load, voltage 1 k
Ω
or greater
Max inductive load, current 0.1 mH
Max inductive load, voltage 1.0 uF
Field calibration None required
Overall accuracy
(3) 0.2% full scale @ 25 °C (77 °F)
Accuracy drift with temperature, current load ±0.0058% FS per °C
Accuracy drift with temperature, voltage load ±0.0086% FS per °C
Output ripple
(4)
range 0…50 kHz
(referred to output range)
±0.05%
Non-linearity (in percent full scale) ±0.05%
Repeatability
(5)
(in percent full scale)
±0.05%
Output error over full temperature range
[0…60°C (32…140°F)], current ±0.4% of full scale
Output error over full temperature range
[0…60°C (32…140°F)], voltage ±0.3% of full scale
Open and short-circuit protection Yes
Max short-circuit current 50 mA
Output overvoltage protection Yes
Rated working voltage 30V AC/30V DC
Output group to bus isolation 500V AC or 710V DC for 1 minute (qualification test)
30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
Channel diagnostics High or Low Clamps Limit Exceeded, by status bit reporting
(1) The over- or under-range flag will come on when the normal operating range (over/under) is exceeded. The module will continue to convert the analog input up to the
maximum full scale range. The flag automatically resets when within the normal operating range unless configured to latch.
(2) Step response is the period of time between when the D/A converter was instructed to go from minimum to full range until the device is at 63% of full range.
(3) Includes offset, gain, drift, non-linearity and repeatability error terms.
(4) Output ripple is the amount a fixed output varies with time, assuming a constant load and temperature.
(5) Repeatability is the ability of the output module to reproduce output readings when the same controller value is applied to it consecutively, under the same conditions and
in the same direction.
