Publication 1769-UM019A-EN-P - October 2008 69
Appendix
A
Specifications
Introduction
General Specifications
Topic Page
General Specifications 69
Input Specifications 70
Output Specifications 71
Certifications 72
Replacement Parts 72
Attribute Value
Dimensions (HxWxD), approx. 118 x 87 x 35 mm (4.65 x 3.43 x 1.38 in.)
Height including mounting tabs is 138 mm (5.43 in.)
Shipping weight, approx. (with carton) 290 g (0.64 lb)
Temperature, storage -40…85 °C (-40…185 °F)
Temperature, operating 0…60 °C (32…140 °F)
Operating humidity 5…95% noncondensing
Operating altitude 2000 m (6561 ft)
Vibration, operating 10…500 Hz, 5 g, 0.030 in. peak-to-peak
Shock, operating 30 g, 11 ms panel-mounted (20 g, 11 ms DIN rail-mounted)
Shock, nonoperating 40 g panel-mounted (30 g DIN rail-mounted)
Bus current draw, max 220 mA @ 5V DC
120 mA @ 24V DC
Heat dissipation 3.39 total Watts (Watts per point plus the minimum Watts with all points energized.)
Module OK status indicator On: The module has power, has passed internal diagnostics, and is communicating over
the bus.
Off: Any of the above is not true.
System power supply distance rating The module may not be more than 8 modules away from the system power supply.
Recommended cable Belden 8761 (shielded)
Vendor I.D. code 1
Product type code 10
Product code 43
Input words 10
Output words 2
Configuration words 42
