Page 58

58
Publikation 1763-IN001C-MU-P – September 2007
Eingangsspezifikationen
Leitungsgebun-
dene Emissionen
EN 55011
AC-Netzteileingang: 150 kHz–30 MHz
Abgestrahlte
Emissionen
EN 55011
30–1000 MHz
Leitungsbezogene
Prüfungen
EN 61000-4-11
AC-Netzteileingang:
Spannungsabfall: –30 % für 10 ms, –60 % für 100 ms
Spannungsunterbrechung: bei Spannungen größer als –95 % für 5 s
Spannungsschwankungen: +10 % für 15 min, –10 % für 15 min
DC-Netzteileingang:
Spannungsschwankungen: +20 % für 15 min, –20 % für 15 min
Digitale Eingänge
Beschreibung
1763-L16AWA
1763-L16BWA, -L16BBB
Eingänge 0 bis 3
(4 DC-Hochgeschwindig-
keitseingänge)
Eingänge 4 und höher
(6 DC-Standardeingänge)
Spannungs-
bereich für
EIN-Zustand
79–132 V AC
14–24 V DC
(14–26,4 V DC (+10 %) bei 65 °C)
(14–30 V DC (+25 %) bei 30 °C)
10–24 V DC
(10–26,4 V DC (+10 %)
bei 65 °C)
(10–30 V DC (+25 %)
bei 30 °C)
Spannungs-
bereich für
AUS-Zustand
0–20 V AC
0–5 V DC
Betriebsfrequenz
47–63 Hz
0 Hz–20 kHz
0 Hz–1 kHz
(Abtastzeit abhängig von
Programmzykluszeit)
Allgemeine technische Daten
Beschreibung
1763-
L16AWA
L16BWA
L16BBB
L16DWD
