6 - 1779 kp5 troubleshooting tools, Chapter objectives, Replacing circuit boards – Rockwell Automation 1779-KP5_KP5R ORD.1779-5.3 User Manual
Page 56
Chapter
6
6Ć1
1779ĆKP5 Troubleshooting Tools
In this chapter, we provide information on:
Replacing circuit boards in your 1779-KP5.
Using LED indicators on the front of the 1779-KP5.
Using the 1779-KP5 diagnostic status bytes and a list of the status
information.
Using the 1779-KP5 diagnostic counters and a list of the counters.
Error codes that may be sent to your node when communicating with
the 1779-KP5.
The 1779-KP5 and 1779-KP5R have three replaceable circuit boards
(Figure 6.1).
Figure 6.1
Replaceable Circuit Boards Inside the 1779ĆKP5
Shield
Power Supply Board
MAC Board
Host Board
12617
Chapter Objectives
Replacing Circuit Boards
