Introduction
Chapter 1
1–4
Table 1.B
Manuals for Allen-Bradley Programmable Controllers
Controller
Old
Number
New
Number Manual TItle
Mini-PLC-2
Program. Cont. 1772-820
1772-821 1772-6.6.3
1772-6.8.4 Assembly and Installation
Programming and Operation
Mini-PLC-2/05 1772-830
1772-831 1772--6.6.6
1772-6.8.6 Assembly and Installation
Programming and Operations
Mini-PLC-2/15
Program. Cont. 1772-803
1772-804 1772-6.6.1
1774-6.8.2 Assembly and Installation
Programming and Operations
PLC-2/20
Program. Cont. 1772-807
1772-802 1772-6.6.2
1772-6.8.1 Assembly and Installation
Programming and Operations
PLC-2/30
Program. Cont. 1772-807
1772-806 1772-6.6.2
1772-6.8.3 Assembly and Installation
Programming and Operations
PLC
Program. Cont. 1774-812
1774-800 1774-6.6.2
1774-6.8.1 Assembly and Installation
Programming and Operations
PLC-3
Program. Cont. 1775-800
1775-801 1775-6.7.1
1775-6.4.1 Installation and Operations
Programming
PLC-4 Microtrol 1773-800 1773-6.5.1 Product Guide
To use this manual, 1772-6.5.1, knowledge of the particular
progammable controller being used in your application is essential.
Because you connect the communication adapter module to an operating
programmable controller, you must have a good understanding of
programmable controller operation, installation, memory structure, and
programming.
Publications are available for each Allen-Bradley programmable
controller. All publications in Table 1.A and Table 1.B are available from
an A-B sales office, or from Allen-Bradley Publications, 6100 Industrial
Court, Greendale, WI 53129.
Features of a 1772-KA2
Here are some of the KA2’s features:
New commands have been added to the 1771-KA2 that simplify
upload and download procedures.
A KA2 lets you to change (remotely) the size of the PC data table.
(New with 1772-KA2 module.)
It has second module or “daisy chain” capability. (New with 1772-KA
2 module.)
Uses ladder diagram instructions for ease of programming.
Offers memory write protection through programming and switch
selection.
