1-6 Install the 1784-PCIC or 1784-PCICS Communication Interface Card
Publication 1784-IN003D-EN-P - January 2006
Insert the Card Into the Computer
1. Handle the card so that you prevent electrostatic discharge.
Refer to the Preface of this manual for more information.
2. Insert the card into the edge connector and tighten the expansion slot screw
(if present).
3. Replace the computer cover.
4. Turn on the computer to be certain that it comes up correctly.
WARNING
When used in a Class I, Division 2, hazardous location,
this equipment must be mounted in a suitable enclosure
with proper wiring method that complies with the
governing electrical codes.
If you insert or remove the card while host power is on,
an electrical arc can occur. This could cause an
explosion in hazardous location installations.
Be sure that power is removed or the area is
nonhazardous before proceeding.
If the Computer
Then
Turns on
Go to to the next section, Connect to the Network
Hangs up
Either the card is not seated correctly in the PCI slot or you have a
memory or I/O conflict. You should:
•
remove and reinsert the card into the same PCI slot and
try again
•
remove and reinsert the card into a different PCI slot and
try again
•
remove all other non-essential cards and try again
If you continue to experience difficulty, contact your local
Rockwell Automation sales representative or distributor, or call
Rockwell Automation Technical Support at 440.646.5800.
