47
Publication 1747-UM655B-EN-P - June 2007
Chapter
4
Configuring the DeviceNet Network
What This Chapter Contains
This chapter describes how to configure the DeviceNet network by
using RSLinx and RSNetWorx for DeviceNet software.
Installing the Software
Follow these steps to install the RSLinx and RSNetWorx for DeviceNet
software.
1. Insert the software CD-ROM in the drive.
The CD-ROM supports Windows Autorun. If you have Autorun
configured, the installation automatically starts when you insert
the CD-ROM in your drive. If you do not have Autorun
configured, perform steps 2 and 3.
2. Select Run from the Windows Start menu.
3. Browse for the Setup program on the CD ROM and open it.
4. Follow the prompts that appear as you install the software.
After software installation is complete, you use RSLinx software to
configure your DeviceNet driver and RSNetWorx for DeviceNet
software to configure the network.
Topic
Page
Use RSLinx Software to Configure the DeviceNet Driver
Using RSNetWorx for DeviceNet Software to Configure the 1747-SDN
Module Scanlist
Verify the Photoeye Configuration
Verify the RediSTATION Configuration
57
AutoMap the Devices into the Scanlist
